What IP66/67 and IK10 Ratings Actually Mean for an Outdoor Camera Deployment

When evaluating outdoor security cameras, IP66/67 and IK10 ratings appear regularly in product specifications. They are shorthand for how well a camera is protected against environmental exposure and physical impact, but what those numbers actually mean in practical terms is not always explained clearly.

What IP Ratings Mean

IP stands for Ingress Protection. It is an international standard defined by the IEC 60529 specification that describes how well an enclosure is sealed against the intrusion of solid particles and liquids. The two digits in an IP rating each refer to a different type of protection. The first digit covers protection against solid objects such as dust, and the second covers protection against water.

For outdoor cameras, the most relevant ratings are IP66 and IP67. Both indicate complete protection against dust ingress, which is the highest level of solid particle protection in the standard. Where they differ is in how they handle water exposure.

IP66 means the camera can withstand powerful water jets from any direction without water entering the housing. This covers the kind of sustained rain, pressure washing, or spray exposure that outdoor cameras regularly encounter in active environments. IP67 adds immersion protection, meaning the camera can be submerged in water up to one meter deep for up to thirty minutes without damage. For most outdoor fixed site deployments, IP66 protection addresses the real-world conditions the camera will face. IP67 adds a further margin of protection in environments where water pooling, flooding, or washdown with high-pressure equipment is a realistic possibility.

Cameras rated for both IP66 and IP67 provide the broadest level of water protection available at this tier of the standard, covering both sustained directional water exposure and temporary immersion.

What IK10 Means

IK ratings are a separate standard defined by IEC/EN 62262 that measure a camera’s resistance to mechanical impact. The scale runs from IK00, which offers no protection, through IK10, which is the highest rating in the standard. An IK10 rating means the camera housing can withstand an impact of 20 joules, equivalent to a five-kilogram object dropped from 40 centimeters, without the housing cracking, deforming, or allowing intrusion.

In practical terms, IK10 means the camera is built to hold up against deliberate attempts to damage or disable it, as well as accidental impacts from equipment, vehicles, or activity in the surrounding environment. For cameras mounted in accessible outdoor locations such as loading docks, parking areas, construction sites, or facility perimeters, that level of physical durability is directly relevant to how reliably the camera performs over time.

A camera with strong image quality and environmental protection but a low impact resistance rating can be rendered ineffective by a single physical incident. IK10 is the standard that addresses that risk.

Why Both Ratings Matter Together

IP and IK ratings address two distinct but equally important aspects of outdoor camera durability. Environmental protection determines whether the camera’s internal components survive exposure to water and dust over time. Impact resistance determines whether the housing itself stays intact when the camera is subjected to physical force.

A camera with strong IP ratings but low impact resistance may survive many years of rain and temperature variation but fail after a single physical incident. A camera with strong IK ratings but inadequate IP protection may hold up physically but suffer internal damage from water ingress over a sustained deployment. For outdoor environments where both weather exposure and physical contact are realistic factors, having both ratings at the appropriate level is what ensures consistent, long-term performance.

The environments where this combination matters most include:

• Fleet yards and depots where vehicles move through regularly and cameras are mounted at accessible heights.

• Construction sites where equipment, dust, and physical activity create ongoing stress on mounted hardware.

• Facility perimeters and entry points where cameras may be subject to deliberate tampering or accidental contact.

• Outdoor public spaces where cameras are visible and accessible to the public.

• Any environment where cameras are regularly cleaned or maintained with pressure washing or high-volume water.

In each of these situations, a camera rated for both IP66/67 and IK10 is built to perform reliably through the conditions it will actually face rather than requiring replacement or repair after normal operational exposure.

Which Pelco Cameras Carry These Ratings

For organizations deploying Pelco cameras through the Samsara ecosystem, SCVS carries several options with verified IP66/67 and IK10 ratings across different form factors and price points, making it possible to match the right camera to each outdoor location without compromising on protection standards.

The following outdoor cameras available through SCVS carry both IP66/67 and IK10 ratings:

• Pelco Sarix Professional 4 Series Bullet: Designed for directed outdoor coverage at longer distances. Available in 2MP through 8MP with varifocal lens options and up to 130 dB Wide Dynamic Range. Well suited for perimeter monitoring, gate entries, and approaches where a fixed forward-facing field of view is needed.

• Pelco Sarix Professional 4 Series Environmental Dome: Offers a wider coverage angle in a lower-profile outdoor housing. Available in the same resolution range as the bullet. A strong choice for building entries, loading areas, and outdoor gathering points where broader area coverage is more useful than long-distance reach.

• Pelco Sarix Value 2 Series Bullet: An accessible entry point into outdoor camera coverage without sacrificing the core protection standards that outdoor deployments require. Available in 2MP and 5MP with varifocal lens options and IR illumination up to 30 meters.

• Pelco Sarix Value 2 Series Outdoor Dome: The dome form factor of the Value 2 Series, offering wide area coverage in a compact housing. Available in 2MP and 5MP with the same IP66/67 and IK10 housing protection as the bullet.

• Pelco Sarix Fisheye 3 Camera - Environmental Models: Designed for wide open spaces where a single camera needs to provide 180 or 360 degree coverage from a wall or ceiling mounted position. Available in 8MP and 12MP. The environmental models carry IP66/67 and IK10 ratings. The indoor models are rated for indoor use only and do not carry the same environmental certifications.

The Pelco Sarix Value Varifocal Turret is also available through SCVS and carries an IP66 rating, providing solid water and dust protection for outdoor use. It does not carry an IK10 rating, which is worth considering when evaluating it for locations where physical impact is a realistic concern.

How SCVS Helps You Choose the Right Camera for Each Location

Understanding what IP66/67 and IK10 ratings mean is useful context when evaluating outdoor cameras, but applying that knowledge to a specific deployment requires an understanding of the environment, the coverage requirements, and how the camera will be mounted and used over time. Not every outdoor location has the same risk profile, and the right camera for one site may not be the right camera for another.

SCVS is Samsara’s recommended partner for Pelco camera deployments within the Samsara ecosystem. Every deployment begins with a site assessment that covers coverage requirements, environmental conditions, mounting positions, and how each camera will function within the Samsara platform. Camera selection is part of that process, and our team ensures that the cameras specified for each location are appropriately rated for the conditions they will be deployed in.

If you are evaluating outdoor cameras for a Samsara Site Visibility deployment and want to talk through which options are the right fit for your specific locations, we offer a free discovery call to help you assess your environment and identify the right setup. We would be glad to connect. Get in touch with our team.
